Combination Layout D Sub Connectors

Farnell provides combination layout D-Sub connectors that integrate signal, power, and coaxial contacts in a single interface. These connectors offer space-saving solutions for mixed-signal transmission.

Combination D-Subs are designed with custom pin arrangements that allow multiple functions within one connector. This versatility reduces wiring complexity and improves system reliability.

Applications

Industrial control units
Telecom and networking hardware
Military-grade electronics
Medical diagnostic devices
Broadcast equipment

Manufacturer Part No	Order Code	Manufacturer / Description	Price For	Price (Incl GST)	Product Range	Insert Arrangement	Gender	No. of Contacts	Contact Type	Contact Termination Type	Connector Mounting	Connector Body Material	Contact Material	Contact Plating

09 69 401 5136	1707676 Data Sheet RoHS	HARTING Combination Layout D Sub Connector Mixed Signal D Sub-M DC-13W6 Receptacle 13 Contacts	Each	1+ $27.910($30.70) 10+ $24.420($26.86) 25+ $20.240($22.26) 100+ $18.140($19.95) 250+ $16.750($18.42)	D Sub-M	DC-13W6	Receptacle	13Contacts	7 Signal, 6 Power	Solder Cup	Cable Mount	Steel Body	Copper Alloy	Gold Plated Contacts
172704-0015	2433167 Data Sheet RoHS	MOLEX / FCT Combination Layout D Sub Connector 172704 Series DC-13W6 Plug 13 Contacts 7 Signal 6 Power	Each	1+ $12.030($13.23) 10+ $10.230($11.25) 100+ $8.680($9.55) 250+ $8.140($8.95) 500+ $7.970($8.77) More Pricing...	172704 Series	DC-13W6	Plug	13Contacts	7 Signal, 6 Power	Solder Cup	Cable Mount, Panel Mount	Steel Body	Brass	Gold Plated Contacts
173107-0084	3862551 Data Sheet RoHS	MOLEX / FCT Combination Layout D Sub Connector 173107 Series DC-21WA4 Receptacle 21 Contacts	Each	1+ $31.770($34.95) 10+ $27.000($29.70) 25+ $25.300($27.83) 100+ $22.930($25.22) 250+ $21.410($23.55) More Pricing...	173107 Series	DC-21WA4	Receptacle	21Contacts	17 Signal, 4 Power	Solder	Panel Mount, Through Hole Mount	Steel Body	Copper Alloy	Gold Plated Contacts
MHCDD5W1P4	4218161 RoHS	MH CONNECTORS Combination Layout D Sub Connector MHCD Series DE-5W1 Plug 5 Contacts 4 Signal 1 Power	Each	1+ $6.250($6.88) 10+ $5.760($6.34) 100+ $5.010($5.51) 250+ $4.910($5.40) 500+ $4.810($5.29) More Pricing...	MHCD Series	DE-5W1	Plug	5Contacts	4 Signal, 1 Power	Solder	Through Hole Mount	Steel Body	Copper Alloy	Gold Flash Plated Contacts
MHCDD5W1S4	4218166 RoHS	MH CONNECTORS Combination Layout D Sub Connector MHCD Series DE-5W1 Receptacle 5 Contacts	Each	1+ $6.770($7.45) 10+ $6.250($6.88) 100+ $5.890($6.48) 250+ $5.340($5.87) 500+ $5.170($5.69) More Pricing...	MHCD Series	DE-5W1	Receptacle	5Contacts	4 Signal, 1 Power	Solder	Through Hole Mount	Steel Body	Copper Alloy	Gold Flash Plated Contacts
173114-0984	3932191 RoHS	MOLEX / FCT Combination Layout D Sub Connector 173114 Series DA-3W3 Receptacle 3 Contacts 3 Power Crimp	1 Kit	1+ $37.330($41.06) 10+ $31.720($34.89) 25+ $29.740($32.71) 100+ $26.520($29.17) 250+ $24.690($27.16) More Pricing...	173114 Series	DA-3W3	Receptacle	3Contacts	3 Power	Crimp	Cable Mount, Panel Mount	Zinc Body	Copper Alloy	Gold Plated Contacts
MHCDS5W5S2	4218151 RoHS	MH CONNECTORS Combination Layout D Sub Connector MHCD Series DB-5W5 Receptacle 5 Contacts 5 Power	Each	1+ $13.670($15.04) 10+ $12.620($13.88) 25+ $11.900($13.09) 100+ $10.780($11.86) 250+ $10.450($11.50) More Pricing...	MHCD Series	DB-5W5	Receptacle	5Contacts	5 Power	Solder Cup	Panel Mount	Steel Body	Copper Alloy	Gold Flash Plated Contacts
173114-0985	3932192 RoHS	MOLEX / FCT Combination Layout D Sub Connector 173114 Series DA-3W3 Plug 3 Contacts 3 Power Solder Cup	1 Kit	1+ $34.700($38.17) 5+ $33.760($37.14) 10+ $32.820($36.10) 25+ $31.880($35.07) 50+ $30.940($34.03) More Pricing...	173114 Series	DA-3W3	Plug	3Contacts	3 Power	Solder Cup	Panel Mount	Zinc Body	Copper Alloy	Gold Plated Contacts
DA3W3PA00LF	1097930 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Combination Layout D Sub Connector Mixed Power FCI DW DA-3W3 Plug 3 Contacts 3 Power	Each	1+ $2.700($2.97) 10+ $2.290($2.52) 100+ $1.950($2.14) 500+ $1.740($1.91) 1000+ $1.650($1.82) More Pricing...	FCI DW	DA-3W3	Plug	3Contacts	3 Power	Solder Cup	Cable Mount	Steel Body	Brass	Gold Plated Contacts
DAM7W2PK87	1557149 Data Sheet RoHS	ITT CANNON CONNECTOR COMBO D PLUG 7 POSITION	Each	1+ $23.890($26.28) 10+ $21.690($23.86) 25+ $20.340($22.37) 100+ $17.990($19.79) 250+ $17.600($19.36) More Pricing...	-	-	-	-	-	Solder	Through Hole Mount	-	-	-
09 69 211 5072	1207582 Data Sheet RoHS	HARTING Combination Layout D Sub Connector Mixed Signal D Sub-M DA-7W2 Plug 7 Contacts	Each	1+ $12.520($13.77) 10+ $11.560($12.72) 100+ $10.660($11.73) 250+ $9.970($10.97) 500+ $9.640($10.60)	D Sub-M	DA-7W2	Plug	7Contacts	5 Signal, 2 Power	Solder Cup	Cable Mount	Metal Body	Copper Alloy	Gold Plated Contacts
DBMM9W4S	8064970 Data Sheet	ITT CANNON CONNECTOR D SUB COMBO RECEPTACLE 9 PO	Each	1+ $28.780($31.66) 10+ $24.470($26.92) 25+ $24.300($26.73) 100+ $24.130($26.54) 250+ $23.960($26.36) More Pricing...	-	-	Receptacle	-	5 Signal, 4 Power	Solder	-	Metal Body	Copper Alloy	-
DBM9W4P	2250624 Data Sheet	ITT CANNON D SUB-MINIATURE	Each	1+ $23.200($25.52) 10+ $22.740($25.01) 25+ $22.280($24.51) 100+ $21.810($23.99) 250+ $21.350($23.48) More Pricing...	Combo D D*M Series	DB-9W4	-	-	-	Solder	-	-	Copper Alloy	Gold Plated Contacts
09 69 201 5072	1207583 Data Sheet RoHS	HARTING Combination Layout D Sub Connector 5 Amp D Sub-M DA-7W2 Receptacle 7 Contacts	Each	1+ $15.880($17.47) 10+ $15.620($17.18) 100+ $15.360($16.90) 250+ $15.060($16.57) 500+ $14.750($16.23)	D Sub-M	DA-7W2	Receptacle	7Contacts	5 Signal, 2 Power	Solder Cup	Cable Mount, Panel Mount	Steel Body	Copper Alloy	Gold Plated Contacts
172704-0013	2433165 Data Sheet RoHS	MOLEX / FCT Combination Layout D Sub Connector 172704 Series DB-13W3 Plug 13 Contacts 10 Signal 3 Power	Each	1+ $12.880($14.17) 10+ $10.960($12.06) 100+ $9.300($10.23) 250+ $8.730($9.60) 500+ $8.300($9.13) More Pricing...	172704 Series	DB-13W3	Plug	13Contacts	10 Signal, 3 Power	Solder Cup	Cable Mount, Panel Mount	Steel Body	Brass	Gold Plated Contacts
173114-0083	2671632 Data Sheet RoHS	MOLEX / FCT Combination Layout D Sub Connector DA-7W2 Plug 7 Contacts 5 Signal 2 Power Solder	Each	1+ $29.870($32.86) 10+ $25.390($27.93) 25+ $23.210($25.53) 100+ $21.570($23.73) 250+ $21.470($23.62) More Pricing...	-	DA-7W2	Plug	7Contacts	5 Signal, 2 Power	Solder	Cable Mount	Zinc Body	-	Gold Plated Contacts
173114-0090	2671639 Data Sheet RoHS	MOLEX / FCT Combination Layout D Sub Connector DB-5W5 Receptacle 5 Contacts 5 Power Solder	Each	1+ $40.120($44.13) 5+ $38.420($42.26) 10+ $36.710($40.38) 25+ $33.800($37.18) 50+ $32.720($35.99) More Pricing...	-	DB-5W5	Receptacle	5Contacts	5 Power	Solder	Cable Mount, Panel Mount	Zinc Body	-	Gold Plated Contacts
680M5W5203L401	3775412 RoHS	NORCOMP Combination Layout D Sub Connector Power-D 680M Series DB-5W5 Receptacle 5 Contacts 3 Power	Each	1+ $23.600($25.96) 10+ $20.890($22.98) 25+ $19.470($21.42) 100+ $17.520($19.27) 250+ $16.420($18.06) More Pricing...	Power-D 680M Series	DB-5W5	Receptacle	5Contacts	3 Power	Solder Cup	Cable Mount	Steel Body	Copper Alloy	Gold Plated Contacts
680S7W2203L201	2294353 RoHS	NORCOMP Combination Layout D Sub Connector 20A IP68 Seal-D 680S Series DA-7W2 Receptacle 7 Contacts	Each	1+ $31.050($34.16) 10+ $27.920($30.71) 25+ $26.400($29.04) 100+ $23.540($25.89) 250+ $22.330($24.56) More Pricing...	Seal-D 680S Series	DA-7W2	Receptacle	7Contacts	5 Signal, 2 Power	Solder Cup	Cable Mount	Steel Body	Copper Alloy	Gold Plated Contacts
L77TWC8W8S	2401232 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Combination Layout D Sub Connector TW Hybrid TW Hybrid D Sub DC-8W8 Receptacle 8 Contacts	Each	1+ $6.820($7.50) 10+ $5.800($6.38) 100+ $5.180($5.70) 250+ $4.700($5.17) 500+ $4.470($4.92) More Pricing...	TW Hybrid D Sub	DC-8W8	Receptacle	8Contacts	8 Power	Solder Cup	Cable Mount	Steel Body	Bronze	Gold Plated Contacts
680S13W3103L401	2294339 RoHS	NORCOMP Combination Layout D Sub Connector 40A IP68 Seal-D 680S Series DB-13W3 Plug 13 Contacts	Each	1+ $27.930($30.72) 10+ $24.660($27.13) 25+ $23.130($25.44) 100+ $20.140($22.15) 250+ $19.840($21.82) More Pricing...	Seal-D 680S Series	DB-13W3	Plug	13Contacts	10 Signal, 3 Power	Solder Cup	Cable Mount	Steel Body	Copper Alloy	Gold Plated Contacts
09 69 301 5133	1207585 Data Sheet RoHS	HARTING Combination Layout D Sub Connector Mixed Signal D Sub-M DB-13W3 Receptacle 13 Contacts	Each	1+ $21.070($23.18) 10+ $19.460($21.41) 25+ $17.950($19.74) 100+ $16.770($18.45) 250+ $16.220($17.84)	D Sub-M	DB-13W3	Receptacle	13Contacts	10 Signal, 3 Power	Solder Cup	Cable Mount	Steel Body	Copper Alloy	Gold Plated Contacts
681M7W2203L001	2421129 RoHS	NORCOMP Combination Layout D Sub Connector Power-D 681M Series DA-7W2 Receptacle 7 Contacts	Each	1+ $20.470($22.52) 10+ $18.220($20.04) 25+ $16.220($17.84) 100+ $14.980($16.48) 250+ $14.250($15.68) More Pricing...	Power-D 681M Series	DA-7W2	Receptacle	7Contacts	5 Signal, 2 Power	Solder	Through Hole Mount	Steel Body	Copper Alloy	Gold Plated Contacts
173114-0085	2671634 Data Sheet RoHS	MOLEX / FCT Combination Layout D Sub Connector DA-3W3 Plug 3 Contacts 3 Power Solder	Each	1+ $28.080($30.89) 10+ $24.310($26.74) 25+ $22.800($25.08) 100+ $19.240($21.16) 250+ $19.120($21.03) More Pricing...	-	DA-3W3	Plug	3Contacts	3 Power	Solder	Cable Mount, Panel Mount	Zinc Body	-	Gold Plated Contacts
L77TWA7W2S	2401225 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Combination Layout D Sub Connector TW Hybrid TW Hybrid D Sub DA-7W2 Receptacle 7 Contacts	Each	1+ $12.040($13.24) 10+ $10.230($11.25) 100+ $9.140($10.05) 250+ $8.280($9.11) 500+ $7.890($8.68) More Pricing...	TW Hybrid D Sub	DA-7W2	Receptacle	7Contacts	5 Signal, 2 Power	Solder Cup	Cable Mount	Steel Body	Bronze	Gold Plated Contacts
